Public 类型

enum RuleType {
RuleTypeEdgeDumb , RuleTypeEdgeChain , RuleTypeEdgeTangent , RuleTypeEdgeFace ,
RuleTypeEdgeBody , RuleTypeEdgeFeature , RuleTypeEdgeSheetBoundary , RuleTypeEdgeBoundary ,
RuleTypeEdgeIntersect , RuleTypeEdgeMultipleSeedTangent , RuleTypeEdgeVertex , RuleTypeEdgeVertexTangent ,
RuleTypeCurveDumb , RuleTypeCurveFeature , RuleTypeCurveFeatureChain , RuleTypeCurveFeatureTangent ,
RuleTypeFollowFillet , RuleTypeFeaturePoints , RuleTypeRegionBoundary , RuleTypeFaceDumb ,
RuleTypeFaceTangent , RuleTypeFaceAdjacent , RuleTypeFaceBody , RuleTypeFaceRegion ,
RuleTypeFaceFeature , RuleTypeFaceConnectedBlend , RuleTypeFaceAllBlend , RuleTypeFaceRib ,
RuleTypeFaceMergedRib , RuleTypeFaceSlot , RuleTypeFaceBossPocket , RuleTypeFaceRegionBoundary ,
RuleTypeFaceAndAdjacentFaces , RuleTypeCurveGroup , RuleTypeBodyDumb , RuleTypeBodyFeature ,
RuleTypeBodyGroup , RuleTypeApparentChaining , RuleTypeOuterFaceEdges , RuleTypeRibTopFaceEdges ,
RuleTypeFeatureIntersectionEdges , RuleTypeFaceHole , RuleTypeTangentSheetBodies , RuleTypeAdjacentSheetBodies ,
RuleTypeConnectedSheetBodies , RuleTypeSheetAndAdjacentSheetBodies , RuleTypeFaceCurvatureCrossSectionFaces , RuleTypeEdgeGroupFaceBoundaryEdges ,
RuleTypeInvalidType
}

Public 成员函数
NXOpen::SelectionIntentRule::RuleType	Type ()
virtual	~SelectionIntentRule ()
Public 成员函数继承自 NXOpen::TransientObject
void *	GetHandle ()

详细描述

选择意图规则类

表示NXOpen::SelectionIntentRule ，主要用于收集曲线、边、面和体。收集的意图会作为规则保存在对应的 NXOpen::Section 或NXOpen::ScCollector 中。
创建于NX3.0.0版本。

成员枚举类型说明

◆ RuleType

enum NXOpen::SelectionIntentRule::RuleType

此枚举表示NXOpen::SelectionIntentRule 定义的选择意图规则类型

枚举值
RuleTypeEdgeDumb	详情请参考NXOpen::EdgeDumbRule
RuleTypeEdgeChain	详情请参考NXOpen::EdgeChainRule
RuleTypeEdgeTangent	详情请参考NXOpen::EdgeTangentRule
RuleTypeEdgeFace	详情请参考NXOpen::EdgeFaceRule
RuleTypeEdgeBody	详情请参考NXOpen::EdgeBodyRule
RuleTypeEdgeFeature	详情请参考NXOpen::EdgeFeatureRule
RuleTypeEdgeSheetBoundary	详情请参考NXOpen::EdgeSheetBoundaryRule
RuleTypeEdgeBoundary	详情请参考NXOpen::EdgeBoundaryRule
RuleTypeEdgeIntersect	详情请参考NXOpen::EdgeIntersectRule
RuleTypeEdgeMultipleSeedTangent	详情请参考NXOpen::EdgeMultipleSeedTangentRule
RuleTypeEdgeVertex	详情请参考NXOpen::EdgeVertexRule
RuleTypeEdgeVertexTangent	详情请参考NXOpen::EdgeVertexTangentRule
RuleTypeCurveDumb	详情请参考NXOpen::CurveDumbRule
RuleTypeCurveFeature	详情请参考NXOpen::CurveFeatureRule
RuleTypeCurveFeatureChain	详情请参考NXOpen::CurveFeatureChainRule
RuleTypeCurveFeatureTangent	详情请参考NXOpen::CurveFeatureTangentRule
RuleTypeFollowFillet	详情请参考NXOpen::FollowFilletRule
RuleTypeFeaturePoints	详情请参考NXOpen::FeaturePointsRule
RuleTypeRegionBoundary	详情请参考NXOpen::RegionBoundaryRule
RuleTypeFaceDumb	详情请参考NXOpen::FaceDumbRule
RuleTypeFaceTangent	详情请参考NXOpen::FaceTangentRule
RuleTypeFaceAdjacent	详情请参考NXOpen::FaceAdjacentRule
RuleTypeFaceBody	详情请参考NXOpen::FaceBodyRule
RuleTypeFaceRegion	详情请参考NXOpen::FaceRegionRule
RuleTypeFaceFeature	详情请参考NXOpen::FaceFeatureRule
RuleTypeFaceConnectedBlend	详情请参考NXOpen::FaceConnectedBlendRule
RuleTypeFaceAllBlend	详情请参考NXOpen::FaceAllBlendRule
RuleTypeFaceRib	详情请参考NXOpen::FaceRibFacesRule
RuleTypeFaceMergedRib	详情请参考NXOpen::FaceMergedRibFacesRule
RuleTypeFaceSlot	详情请参考NXOpen::FaceSlotFacesRule
RuleTypeFaceBossPocket	详情请参考NXOpen::FaceBossPocketFacesRule
RuleTypeFaceRegionBoundary	详情请参考NXOpen::FaceRegionBoundaryRule
RuleTypeFaceAndAdjacentFaces	详情请参考NXOpen::FaceAndAdjacentFacesRule
RuleTypeCurveGroup	详情请参考NXOpen::CurveGroupRule
RuleTypeBodyDumb	详情请参考NXOpen::BodyDumbRule
RuleTypeBodyFeature	详情请参考NXOpen::BodyFeatureRule
RuleTypeBodyGroup	详情请参考NXOpen::BodyGroupRule
RuleTypeApparentChaining	详情请参考NXOpen::ApparentChainingRule
RuleTypeOuterFaceEdges	详情请参考NXOpen::OuterEdgesOfFacesRule
RuleTypeRibTopFaceEdges	详情请参考NXOpen::RibTopFaceEdgesRule
RuleTypeFeatureIntersectionEdges	详情请参考NXOpen::FeatureIntersectionEdgesRule
RuleTypeFaceHole	详情请参考NXOpen::FaceHoleFacesRule
RuleTypeTangentSheetBodies	详情请参考NXOpen::TangentSheetBodiesRule
RuleTypeAdjacentSheetBodies	详情请参考NXOpen::AdjacentSheetBodiesRule
RuleTypeConnectedSheetBodies	详情请参考NXOpen::ConnectedSheetBodiesRule
RuleTypeSheetAndAdjacentSheetBodies	详情请参考NXOpen::SheetAndAdjacentSheetBodiesRule
RuleTypeFaceCurvatureCrossSectionFaces	详情请参考NXOpen::FaceCurvatureCrossSectionFacesRule
RuleTypeEdgeGroupFaceBoundaryEdges	详情请参考NXOpen::EdgeGroupFaceBoundaryEdgesRule
RuleTypeInvalidType	无效的选择意图规则类型。

构造及析构函数说明

◆ ~SelectionIntentRule()

virtual NXOpen::SelectionIntentRule::~SelectionIntentRule ( )

virtual

释放与实例关联的资源。调用此方法后，该对象将不可再使用。在.NET中，当垃圾回收器删除对象时会自动调用此方法。
创建于NX3.0.0版本。

许可要求: 无

成员函数说明

◆ Type()

NXOpen::SelectionIntentRule::RuleType NXOpen::SelectionIntentRule::Type ( )

获取选择意图规则的类型: NXOpen::SelectionIntentRule
创建于NX3.0.0版本。

许可要求: 网关功能("UG GATEWAY")
