NXOpen::INXObject类 参考

NX对象基础接口 更多...

#include <INXObject.hxx>

类 NXOpen::INXObject 继承关系图:

Public 成员函数
virtual NXOpen::INXObject *	FindObject (const char *journalIdentifier)=0
virtual NXOpen::INXObject *	FindObject (const NXString &journalIdentifier)=0
virtual bool	IsOccurrence ()=0
virtual NXString	JournalIdentifier ()=0
virtual NXString	Name ()=0
virtual NXOpen::Assemblies::Component *	OwningComponent ()=0
virtual NXOpen::BasePart *	OwningPart ()=0
virtual void	Print ()=0
virtual NXOpen::INXObject *	Prototype ()=0
virtual void	SetName (const char *name)=0
virtual void	SetName (const NXString &name)=0

详细描述

NX对象基础接口

表示大多数NXOpen类继承的接口
创建于NX3.0.0。

成员函数说明

FindObject() [1/2]

virtual NXOpen::INXObject * NXOpen::INXObject::FindObject ( const char * journalIdentifier )

pure virtual

查找具有日志中记录的给定标识符的NXOpen::NXObject 。 软件不同版本中，对象的JournalIdentifier值可能不同。但软件新版本通过旧版本的日志标识符调用FindObject时，应能找到同一对象。通常，此方法不应在手写代码中使用，仅用于支持日志的录制和回放。 若找不到具有给定日志标识符的对象，将抛出异常。

返回

创建于NX3.0.0。

许可证要求：无

参数

journalIdentifier

对象的日志标识符

在 NXOpen::CAE::DurSpecialistDurWeldSet, NXOpen::CAE::FEElement, NXOpen::CAE::FENode, NXOpen::CAE::PenetrationCheck::AnalysisSet, NXOpen::CAE::PenetrationCheck::ResultList, NXOpen::CAM::NCGroup, NXOpen::Features::TopologyOptimizationFeature, NXOpen::GeometricAnalysis::PerformancePredictor, NXOpen::GeometricUtilities::DegreesAndSegmentsOrPatchesBuilder, NXOpen::GeometricUtilities::OnPathDimWithValueBuilder, NXOpen::GeometricUtilities::RotationSetBuilder, NXOpen::Mfg::AM::ProfileLibrary, NXOpen::Mfg::Mlp::Line, NXOpen::Mfg::Mlp::Operation, NXOpen::Mfg::Mlp::Part, NXOpen::Mfg::Mlp::ProcessPlan, NXOpen::Mfg::Mlp::ProcessSetup, NXOpen::Mfg::Mlp::Product, NXOpen::Mfg::Mlp::ToolSet, NXOpen::Mfg::Mlp::Workpiece, NXOpen::NXObject, NXOpen::Report::BaseArgument, NXOpen::Report::CommandLibrary, NXOpen::Report::ProgramInformation , 以及 NXOpen::Report::UserInput 内被实现.

FindObject() [2/2]

virtual NXOpen::INXObject * NXOpen::INXObject::FindObject ( const NXString & journalIdentifier )

pure virtual

查找具有日志中记录的给定标识符的NXOpen::NXObject 。 软件不同版本中，对象的JournalIdentifier值可能不同。但软件新版本通过旧版本的日志标识符调用FindObject时，应能找到同一对象。通常，此方法不应在手写代码中使用，仅用于支持日志的录制和回放。 若找不到具有给定日志标识符的对象，将抛出异常。

返回

创建于NX3.0.0。

许可证要求：无

参数

journalIdentifier

对象的日志标识符

在 NXOpen::CAE::DurSpecialistDurWeldSet, NXOpen::CAE::FEElement, NXOpen::CAE::FENode, NXOpen::CAE::PenetrationCheck::AnalysisSet, NXOpen::CAE::PenetrationCheck::ResultList, NXOpen::CAM::NCGroup, NXOpen::Features::TopologyOptimizationFeature, NXOpen::GeometricAnalysis::PerformancePredictor, NXOpen::GeometricUtilities::DegreesAndSegmentsOrPatchesBuilder, NXOpen::GeometricUtilities::OnPathDimWithValueBuilder, NXOpen::GeometricUtilities::RotationSetBuilder, NXOpen::Mfg::AM::ProfileLibrary, NXOpen::Mfg::Mlp::Line, NXOpen::Mfg::Mlp::Operation, NXOpen::Mfg::Mlp::Part, NXOpen::Mfg::Mlp::ProcessPlan, NXOpen::Mfg::Mlp::ProcessSetup, NXOpen::Mfg::Mlp::Product, NXOpen::Mfg::Mlp::ToolSet, NXOpen::Mfg::Mlp::Workpiece, NXOpen::NXObject, NXOpen::Report::BaseArgument, NXOpen::Report::CommandLibrary, NXOpen::Report::ProgramInformation , 以及 NXOpen::Report::UserInput 内被实现.

IsOccurrence()

virtual bool NXOpen::INXObject::IsOccurrence ( )

pure virtual

返回此对象是否为实例。
创建于NX3.0.0。

许可证要求：无

在 NXOpen::CAE::FEElement, NXOpen::CAE::FENode, NXOpen::GeometricUtilities::DegreesAndSegmentsOrPatchesBuilder, NXOpen::GeometricUtilities::OnPathDimWithValueBuilder, NXOpen::GeometricUtilities::RotationSetBuilder, NXOpen::NXObject, NXOpen::Report::BaseArgument, NXOpen::Report::CommandLibrary, NXOpen::Report::ProgramInformation , 以及 NXOpen::Report::UserInput 内被实现.

JournalIdentifier()

virtual NXString NXOpen::INXObject::JournalIdentifier ( )

pure virtual

返回此对象在日志中记录的标识符。 软件不同版本间此标识符可能不同。
创建于NX3.0.0。

许可证要求：无

在 NXOpen::CAE::FEElement, NXOpen::CAE::FENode, NXOpen::GeometricUtilities::DegreesAndSegmentsOrPatchesBuilder, NXOpen::GeometricUtilities::OnPathDimWithValueBuilder, NXOpen::GeometricUtilities::RotationSetBuilder, NXOpen::NXObject, NXOpen::Report::BaseArgument, NXOpen::Report::CommandLibrary, NXOpen::Report::ProgramInformation , 以及 NXOpen::Report::UserInput 内被实现.

Name()

virtual NXString NXOpen::INXObject::Name ( )

pure virtual

返回对象的自定义名称。
创建于NX3.0.0。

许可证要求：无

在 NXOpen::AME::TemplateVariant, NXOpen::AME::TemplateVariantSelection, NXOpen::CADCAEPrep::IBeamSection, NXOpen::CAE::AcousticsAndVibrationAcousticRadiatingSurfaceComponentAccessor, NXOpen::CAE::AcousticsAndVibrationBcComponentAccessor, NXOpen::CAE::AeroStructures::Author::CalculationContext, NXOpen::CAE::AeroStructures::Author::InputParameter, NXOpen::CAE::AeroStructures::Author::OutputParameter, NXOpen::CAE::AeroStructures::BaseExtractionSource, NXOpen::CAE::CurveOperationExpressionRecord, NXOpen::CAE::DataSource, NXOpen::CAE::FEElement, NXOpen::CAE::FENode, NXOpen::CAE::LaminateGlobalLayup, NXOpen::CAE::LaminateLayupOffset, NXOpen::CAE::LaminateMatOrientation, NXOpen::CAE::LaminatePlyGroup, NXOpen::CAE::LaminatePlySection, NXOpen::CAE::LaminatePostReport, NXOpen::CAE::ModelAndLoadPreProcessIntermediaryMeshGroup, NXOpen::CAE::Optimization::DAOSolution, NXOpen::CAE::PreTestSensorConfig, NXOpen::CAE::PreTestSolution, NXOpen::CAE::SimRayAcousticsToolsSetupWizard, NXOpen::CAE::SimSoundProcessing, NXOpen::CAE::SimSoundProcessingTransfer, NXOpen::CAE::StressLinearization, NXOpen::CAM::CAMAttribute, NXOpen::CAM::CAMFeature, NXOpen::CAM::FeatureGeometryGroup, NXOpen::CoordinateSystem, NXOpen::DesignSimulation::ResultMeasure, NXOpen::Display::VisualMaterial, NXOpen::Fields::NameVariable, NXOpen::GeometricUtilities::DegreesAndSegmentsOrPatchesBuilder, NXOpen::GeometricUtilities::OnPathDimWithValueBuilder, NXOpen::GeometricUtilities::RotationSetBuilder, NXOpen::MechanicalRouting::Spool, NXOpen::NXObject, NXOpen::PartFamily::FamilyAttribute, NXOpen::Report::BaseArgument, NXOpen::Report::CommandLibrary, NXOpen::Report::ProgramInformation, NXOpen::Report::UserInput , 以及 NXOpen::Routing::Electrical::SplicePoint 内被实现.

OwningComponent()

virtual NXOpen::Assemblies::Component * NXOpen::INXObject::OwningComponent ( )

pure virtual

若此对象为实例，则返回其所属组件。
创建于NX3.0.0。

许可证要求：无

在 NXOpen::CAE::FEElement, NXOpen::CAE::FENode, NXOpen::GeometricUtilities::DegreesAndSegmentsOrPatchesBuilder, NXOpen::GeometricUtilities::OnPathDimWithValueBuilder, NXOpen::GeometricUtilities::RotationSetBuilder, NXOpen::NXObject, NXOpen::Report::BaseArgument, NXOpen::Report::CommandLibrary, NXOpen::Report::ProgramInformation , 以及 NXOpen::Report::UserInput 内被实现.

OwningPart()

virtual NXOpen::BasePart * NXOpen::INXObject::OwningPart ( )

pure virtual

返回此对象的所属部件。
创建于NX3.0.0。

许可证要求：无

在 NXOpen::CAE::FEElement, NXOpen::CAE::FENode, NXOpen::GeometricUtilities::DegreesAndSegmentsOrPatchesBuilder, NXOpen::GeometricUtilities::OnPathDimWithValueBuilder, NXOpen::GeometricUtilities::RotationSetBuilder, NXOpen::NXObject, NXOpen::Report::BaseArgument, NXOpen::Report::CommandLibrary, NXOpen::Report::ProgramInformation , 以及 NXOpen::Report::UserInput 内被实现.

Print()

virtual void NXOpen::INXObject::Print ( )

pure virtual

将此对象的表示打印到系统日志文件。
创建于NX3.0.0。

许可证要求：无

在 NXOpen::CAE::FEElement, NXOpen::CAE::FENode, NXOpen::CAE::PenetrationCheck::AnalysisSet, NXOpen::GeometricUtilities::DegreesAndSegmentsOrPatchesBuilder, NXOpen::GeometricUtilities::OnPathDimWithValueBuilder, NXOpen::GeometricUtilities::RotationSetBuilder, NXOpen::NXObject, NXOpen::Report::BaseArgument, NXOpen::Report::CommandLibrary, NXOpen::Report::ProgramInformation , 以及 NXOpen::Report::UserInput 内被实现.

Prototype()

virtual NXOpen::INXObject * NXOpen::INXObject::Prototype ( )

pure virtual

若此对象为实例，则返回其原型。
创建于NX3.0.0。

许可证要求：无

在 NXOpen::CAE::FEElement, NXOpen::CAE::FENode, NXOpen::GeometricUtilities::DegreesAndSegmentsOrPatchesBuilder, NXOpen::GeometricUtilities::OnPathDimWithValueBuilder, NXOpen::GeometricUtilities::RotationSetBuilder, NXOpen::NXObject, NXOpen::Report::BaseArgument, NXOpen::Report::CommandLibrary, NXOpen::Report::ProgramInformation , 以及 NXOpen::Report::UserInput 内被实现.

SetName() [1/2]

virtual void NXOpen::INXObject::SetName ( const char * name )

pure virtual

设置对象的自定义名称。 注意：此方法不应用于编辑只读对象（如镜像PMI对象）。 若使用，部件更新时更改将被覆盖。
创建于NX3.0.0。

许可证要求：无

参数

name

名称

在 NXOpen::AME::AMEQuery, NXOpen::AME::PlcLogicBlockParameter, NXOpen::AME::ReportDefinition, NXOpen::AME::TemplateVariant, NXOpen::AME::TemplateVariantSelection, NXOpen::CAE::AcousticsAndVibrationAcousticRadiatingSurfaceComponentAccessor, NXOpen::CAE::AcousticsAndVibrationBcComponentAccessor, NXOpen::CAE::CaeGroup, NXOpen::CAE::CfdAutoRefinementConstraint, NXOpen::CAE::CfdContactPreventionConstraint, NXOpen::CAE::CfdLocalResolutionConstraint, NXOpen::CAE::CorrelNodeMapFilter, NXOpen::CAE::CorrelNodeMapMethod, NXOpen::CAE::CurveOperationExpressionRecord, NXOpen::CAE::FEElement, NXOpen::CAE::FENode, NXOpen::CAE::FluidDomainRecipe, NXOpen::CAE::LaminateGlobalLayup, NXOpen::CAE::LaminateLayupOffset, NXOpen::CAE::LaminateMatOrientation, NXOpen::CAE::LaminatePlyGroup, NXOpen::CAE::LaminatePlySection, NXOpen::CAE::LaminatePostReport, NXOpen::CAE::ModelUpdateResponse, NXOpen::CAE::Optimization::DAOSolution, NXOpen::CAE::PreTestSensorConfig, NXOpen::CAE::PreTestSolution, NXOpen::CAE::SelectionRecipe, NXOpen::CAE::SensorSetRef, NXOpen::CAE::SimRayAcousticsToolsSetupWizard, NXOpen::CAE::SimSoundProcessing, NXOpen::CAM::CAMFeature, NXOpen::CAM::FeatureGeometryGroup, NXOpen::Composites::Base, NXOpen::CoordinateSystem, NXOpen::GeometricUtilities::DegreesAndSegmentsOrPatchesBuilder, NXOpen::GeometricUtilities::OnPathDimWithValueBuilder, NXOpen::GeometricUtilities::RotationSetBuilder, NXOpen::NXObject, NXOpen::PartMfg::Element, NXOpen::Report::BaseArgument, NXOpen::Report::CommandLibrary, NXOpen::Report::ProgramInformation, NXOpen::Report::UserInput , 以及 NXOpen::SIM::KinematicConfigurator 内被实现.

SetName() [2/2]

virtual void NXOpen::INXObject::SetName ( const NXString & name )

pure virtual

设置对象的自定义名称。 注意：此方法不应用于编辑只读对象（如镜像PMI对象）。 若使用，部件更新时更改将被覆盖。
创建于NX3.0.0。

许可证要求：无

参数

name

名称

在 NXOpen::AME::AMEQuery, NXOpen::AME::PlcLogicBlockParameter, NXOpen::AME::ReportDefinition, NXOpen::AME::TemplateVariant, NXOpen::AME::TemplateVariantSelection, NXOpen::CAE::AcousticsAndVibrationAcousticRadiatingSurfaceComponentAccessor, NXOpen::CAE::AcousticsAndVibrationBcComponentAccessor, NXOpen::CAE::CaeGroup, NXOpen::CAE::CfdAutoRefinementConstraint, NXOpen::CAE::CfdContactPreventionConstraint, NXOpen::CAE::CfdLocalResolutionConstraint, NXOpen::CAE::CorrelNodeMapFilter, NXOpen::CAE::CorrelNodeMapMethod, NXOpen::CAE::CurveOperationExpressionRecord, NXOpen::CAE::FEElement, NXOpen::CAE::FENode, NXOpen::CAE::FluidDomainRecipe, NXOpen::CAE::LaminateGlobalLayup, NXOpen::CAE::LaminateLayupOffset, NXOpen::CAE::LaminateMatOrientation, NXOpen::CAE::LaminatePlyGroup, NXOpen::CAE::LaminatePlySection, NXOpen::CAE::LaminatePostReport, NXOpen::CAE::ModelUpdateResponse, NXOpen::CAE::Optimization::DAOSolution, NXOpen::CAE::PreTestSensorConfig, NXOpen::CAE::PreTestSolution, NXOpen::CAE::SelectionRecipe, NXOpen::CAE::SensorSetRef, NXOpen::CAE::SimRayAcousticsToolsSetupWizard, NXOpen::CAE::SimSoundProcessing, NXOpen::CAM::CAMFeature, NXOpen::CAM::FeatureGeometryGroup, NXOpen::Composites::Base, NXOpen::CoordinateSystem, NXOpen::GeometricUtilities::DegreesAndSegmentsOrPatchesBuilder, NXOpen::GeometricUtilities::OnPathDimWithValueBuilder, NXOpen::GeometricUtilities::RotationSetBuilder, NXOpen::NXObject, NXOpen::PartMfg::Element, NXOpen::Report::BaseArgument, NXOpen::Report::CommandLibrary, NXOpen::Report::ProgramInformation, NXOpen::Report::UserInput , 以及 NXOpen::SIM::KinematicConfigurator 内被实现.
